iSky-30HD. Multi Sensor HD Observation System for Air Applications

Print
iSky-30HD
iSky-30HD
Main characteristics
SKU 2216
Vendor Controp
Category Long-Range Surveillance
Active range (m) 20000
Display 12"
Interface RS-422, ARINC 429, MIL-STD-1553
Management 5-Z, Auto, manual, slow, priority
Dimensions, HWD Ø 305 mm
Weight 21 kg
Shipment According EUC

Multi Sensor HD Observation Payload System

The iSky-30HD is a compact Day/Night observation system especially configured for UAV, light A/C, helicopter and marine patrol boat applications.
It is easily integrated onto a wide variety of carrying vehicles due to its flexible configuration, making it suitable for most airborne and maritime requirements.
Wide range of communication interfaces to the host vehicle including RS-422, ARINC 429 (optional) and MIL-STD-1553 (optional).
The iSky-30HD is operated by a ruggedized Control Unit (CU) with a thumb LOS control stick and all control switches are specially designed for rough environment conditions and for best human comfort. The CU can be attached to a fixed location or using a flexible cable enabling it to be movable.

MAIN FEATURES

Three (3) Gimbals, Gyro-stabilized

Sensors:

    - Thermal Imaging (TI) Camera with 250 mm focal length (Continuous Zoom X37.5)
    - High Sensitivity Color HD Day Camera (Continuous Zoom X50)
    - Optional Eyesafe Laser Range Finder
    - Optional Laser Illuminator
    - Optional Laser Pointer

High performance and low size/weight:

    - Lightweight – 21.5 kg (turret)
    - Compact – 30.5 cm (turret diameter)

Automatic Target Tracker
Image Enhancement and Local AGC capabilities (Built-in)
Customized graphics superimposed on video
High Performance
Excellent Price/Performance Ratio

APPLICATIONS

Border Patrol
Coast Guard and Sea Patrol
Police Multi Mission
Search and Rescue (SAR)
Anti-terrorist Surveillance
Anti-smuggling Surveillance
Oil Spill Detection
Oil Pipeline Patrol
SHAO-AIR
